Welcome to the Storage Cores Product Page
AES256 - 8 bit datapath
An 8-bit datapath for the AES algorithm ensures the smallest LUT count possible. Offers throughput rates up to 20Mbps
AES256 - 32 BIT datapath
The 32-bit datapath offering provides an optimal tradeoff of algorithm throughput and fabric utilization. Offers throughput ranges from 200 to 300Mbps.
AES256 - 128 bit datapath
The 128-bit datapath core offers a full range of area and speed tradeoffs with 1 to 7 crypto engines available. These options support throughputs from 1 to 12Gbps.
AES256 - 128 bit streaming data with multi-core
The 128-bit streaming AES IP offers maximum performance with each core comprising 14 AES engines allowing a new 128-bit data block to be processed every clock cycle. This IP supports 1, 2, and 4 core options with corresponding streaming AES256 throughput of 25Gbps, 50Gbps, and 100Gbps respectively.
